Tonar Banana Professional DISCO Cartridge
Be the best DJ you can be! The top banana of Disco DJ cartridges, the Tonar Banana Disco phono cartridge is based on the concorde design, the proven and preferred choice for mixing by demanding DJs with a passionf or excellence. An extraordinary cartridge for extraordinary performances, it's designed to perform and showcase the best of your unique style, your sound and your music genre.
Professional, yellow and strong on bass, made by Ortofon . A stylus that meets the high demands of DJs. The special heavy-duty suspension of the headshell and the spherical diamond guarantee reliable tracking.An integrated weight ring creates heaviness thus allowing high bearing strength. The design allows easy installation on all drives with SME-Disco Connection: Tighten the plug in screw cap on the tone arm, adjust contact pressure and even the professional record no bounds are set
Specifications
|
Frequency Response
|
20Hz - 20KHz
|
|
Output @ 1 kHz
|
5mv
|
|
Channel Separation @ 1kHz
|
> 20dB
|
|
Channel Balance @ 1kHz
|
within 2dB
|
|
Stylus Tip Type
|
0.7 mil Spherical Diamond
|
|
Tracking Force
|
3-5 g (30-50 mN)
|
|
Weight (g)
|
16
|
|
Replacement Stylus
|
Tonar no: 1812
|
|
Frequency Characteristics
|
20-20.000 Hz +/- 1 dB
|
|
Dynamic Compliance Horizontal / Vertical
|
8/8 um/mN
|
|
Load Resistance
|
47 K
|
|
Stylus Tip Material
|
Bonded Diamond
|
|
Tip Diameter
|
0,4 mm
|
|
Vertical Tracking Angle
|
20o
|
|
Recommended Load Resistance
|
47 K
|
|
Recommended Load Capacitance
|
400 pF
|
|
Scratching
|
Suitable
|
|
Cartridge Mounting System
|
Suitable for SME-type arm only
|
