Ortofon Hi-Fi 2M 78 Moving Magnet Cartridge
- Spherical diamond that is perfect for playback of 78 rpm shellac records, which require a larger stylus profile
- Uses a strapped output to deliver the same output signal from both sets of pole pins
2M Series
The 2M Series of cartridges from Ortofon have been designed for precise and accurate retrieval of the information in the record groove. Indeed, it is Ortofon's lasting philosophy to only ever play the recorded sound, without colouration. The pre-existing range of 2M cartridges have rapidly been established as a reference point for all good moving magnet cartridges. From the introductory Red, through to the high-end Black; 2M is now a go-to name in moving magnet technology. 2012 sees Ortofon open up new markets within the same design principle of 2M. The 2M 78 and 2M Mono offer users of older, rare vinyl a higher-quality playback medium than had previously been available.
The 2M 78 features an improved True Mono engine, which provides a high level of sonic accuracy, as well as expertly cut Spherical diamond that is perfect for playback of 78 rpm records (which require a larger stylus profile).
2M Verso
The 2M series of cartridges are now also available in a special version, suited for bottom-mount tonearms. The 2M Verso are available to special order.Ā Ā Head-Shell shown for illustration purposes only and not included with cartridge
Features
- Optimised sound reproduction and high level of sonic accuracy
- Spherical diamond that is perfect for playback of 78 rpm shellac records, which require a larger stylus profile
- Uses a strapped output to deliver the same output signal from both sets of pole pins
- Supplied with 2 different sets of screws (M2.5 x 5 & M2.5 x 7)
- Stylus brush included
- Also available with integrated headshell or verso version
Each 2M cartridge model is also available as a 2MR variant. Here, the "R" stands for āReducedā and relates to the lower cartridge body height. This is suited to certain types of tonearms from manufacturers such as Pro-Ject, Linn and Rega, in order to achieve the correct VTA. To learn more about whether the 2MR might be useful for your system, visit our handy technical pageĀ Ortofon 2MR - The Technical ArgumentĀ SuitableĀ For Riga Turntables
Specifications
|
Output Voltage (at 1kHz, 5cm/sec):
|
4mV
|
|
Frequency Range (at -3dB):
|
20Hz - 22kHz
|
|
Frequency Response 20Hz - 20kHz:
|
+3 / -1dB
|
|
Tracking Ability at 315Hz:
|
Typically 70Ī¼m
|
|
Compliance, Dynamic, Lateral:
|
18Ī¼m / mN
|
|
Stylus Type:
|
Spherical
|
|
Stylus Tip Radius R:
|
65Ī¼m
|
|
Tracking Force Range:
|
1.6 - 2.0g (16 - 20mN)
|
|
Recommended Tracking Force:
|
1.8g (18mN)
|
|
Tracking Angle:
|
20Āŗ
|
|
Internal Impedance / DC Resistance:
|
700Ī©
|
|
Internal Inductance:
|
300mH
|
|
Recommended Load Resistance:
|
47kĪ©
|
|
Recommended Load Capacitance:
|
150 - 300pF
|
|
Cartridge Colour Body / Stylus:
|
Black / Grey
|
|
Cartridge Weight:
|
7.2g
|
|
Replacement Stylus Unit:
|
Stylus 2M 78 |
|
Accessories:
|
Stylus Brush
Screwdriver
|
2M 78 |
2MR 78 |
2M 78 Premounted |
|||
|---|---|---|---|---|---|
| Differing Key Features | |||||
| Reduced-height 2MR cartridge body | No | Yes | No | ||
| Overhead mounting cartridge for installing into a headshell | Yes | Yes | No | ||
| Moving magnet cartridge with removable stylus | Yes | Yes | Yes | ||
| Supplied pre-installed on a headshell for easy installation | No | No | Yes | ||
| Special "verso" model for bottom-mount headshells | No | No | No | ||
| Utilises Ortofon's split-pole pin technology to reduce the eddy current and to get a flat frequency response, like with an MC cartridge | Yes | Yes | Yes | ||
| Anti-resonant Hopelex body | Yes | Yes | Yes | ||
| Stylus fits on other models in the Ortofon 2M range | No | No | No | ||
| Replacement stylus only | No | No | No | ||
| Common Key Features | |||||
| Optimised mono output cartridge | |||||
| Optimised for use with 78 RPM records | |||||
| Spherical diamond stylus | |||||
| Differing Specifications | |||||
| Cartridge Weight | 7.2 g | 6 g | 16.7 g | ||
| Replacement Stylus For | |||||
| Common Specifications | |||||
| Output Voltage (@ 1000Hz, 5cm/sec.) | 4 mV | ||||
| Frequency Range (@ -3dB) | 20 - 20000 Hz | ||||
| Frequency Response +3 / -1dB | 20 - 20000 Hz | ||||
| Tracking Ability (@ 315Hz at Recommended Tracking Force) | 70 Ī¼m | ||||
| Compliance, Dynamic, Lateral | 18 Ī¼m | ||||
| Stylus Type | Spherical | ||||
| Tracking Force Range | 1.6 - 2.0 g | ||||
| Recommended Tracking Force | 1.8 g | ||||
| Tracking Angle | 20 Ā° | ||||
| Internal Impedance | 700 Ī© | ||||
| Internal Inductance | 350 mH | ||||
| Cantilever Material | Aluminium Tube | ||||
| Recommended Load Impedance | 47000 Ī© | ||||
| Recommended Load Capacitance | 150 - 300 pF | ||||
